Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 52" X 18"
MAXIMUM TABLE LOAD 3,500 LBS
SPINDLE NOSE TO TABLE TOP 4" - 29"
X AXIS TRAVEL 50"
Y AXIS TRAVEL 20"
Z AXIS TRAVEL 25"
RAPID TRAVERSE RATE X AXIS 500 IPM
RAPID TRAVERSE RATE Y AXIS 500 IPM
RAPID TRAVERSE RATE Z AXIS 500 IPM
CUTTING FEED RATE 0.1 - 200 IPM
SPINDLE SPEEDS 0 - 7,500 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 15 HP
TOOL CHANGER CAPACITY 20 STATION ATC
MAXIMUM TOOL WEIGHT 12 LBS
EQUIPPED WITH:
HAAS 32-BIT CNC CONTROL WITH 12" MONOCHROME CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS TAPPING / SOLID TAPPING)
PROGRAMMABLE COOLANT NOZZLE, COORDINATE ROTATION & SCALING
INTERNAL CHIP CONVEYOR, WIRED FOR 4TH AXIS ROTARY
FULLY ENCLOSED SPLASH GUARDING, ALL AVAILABLE MANUALS
***COMPLETE P/M DONE TO MACHINE LATE JANUARY 2003, INCLUDING
NEW TOOL CAROUSEL, TOOL CHANGE PANELS, OIL DRAIN PLUG,
TOOL CHANGE RELAYS, SHUTTLE MOTOR BRUSHES, Y AXIS WIPERS
