Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 36" X 14"
MAXIMUM TABLE LOAD 3,000 LBS
SPINDLE NOSE TO TABLE TOP 4" - 24"
X AXIS TRAVEL 30"
Y AXIS TRAVEL 16"
Z AXIS TRAVEL 20"
RAPID TRAVERSE RATE X AXIS 710 IPM
RAPID TRAVERSE RATE Y AXIS 710 IPM
RAPID TRAVERSE RATE Z AXIS 710 IPM
CUTTING FEED RATE 0.1 - 500 IPM
SPINDLE SPEEDS (2 SPEED GEARED) 0 - 10,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR (VECTOR DRIVE) 15 HP AC
TOOL CHANGER CAPACITY 20 STATION ATC
MAXIMUM TOOL WEIGHT 12 LBS
EQUIPPED WITH:
HAAS 32-BIT CNC CONTROL WITH 12" CRT, MANUAL PULSE GENERATOR
RS-232C PORT INTERFACE, QUIKCODE PROGRAMMING, 1MB MEMORY
RIGID TAPPING (SYNCHRONOUS TAPPING / SOLID TAPPING
INTERNAL COIL TYPE CHIP REMOVAL CONVEYOR, FLOPPY DRIVE
UPGRADED SOFTWARE TO VERSION 11.2 (LATEST & GREATEST)
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
***667 POWER ON & 294 SPINDLE HOURS, NOT A MISPRINT***
