Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER FRONT APRON 40"
SWING OVER CROSS SLIDE 25"
MAXIMUM CUTTING DIAMETER 25"
MAXIMUM CUTTING LENGTH (UNIVERSAL) 44"
X AXIS TRAVEL 17"
Z AXIS TRAVEL 44"
RAPID TRAVERSE RATE X AXIS 710 IPM
RAPID TRAVERSE RATE Z AXIS 710 IPM
SPINDLE NOSE A2-8
SPINDLE BORE 4.62"
MAXIMUM BAR CAPACITY (ROUND) 4"
SPINDLE SPEEDS 0 - 2,400 RPM
SPINDLE MOTOR 40 HP AC
TURRET CAPACITY 10 STATION TURRET
TURRET INDEX TIME (1 STATION) 1 SECOND
EQUIPPED WITH:
HAAS 32-BIT CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
15" 3-JAW HYDRAULIC CHUCK WITH JAWS
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
QUICK CODE, 1 MEG, INTERNAL TRANSFORMER
STANDARD COOLANT SYSTEM WITH TANK & PUMP
ALL AVAILABLE TOOL HOLDERS & MANUALS
