Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 29.5" x 16"
MAXIMUM TABLE LOAD 750 LBS
SPINDLE NOSE TO TABLE TOP 4" - 24"
X AXIS TRAVEL 20"
Y AXIS TRAVEL 16"
Z AXIS TRAVEL 20"
RAPID TRAVERSE RATE X AXIS 500 IPM
RAPID TRAVERSE RATE Y AXIS 500 IPM
RAPID TRAVERSE RATE Z AXIS 500 IPM
CUTTING FEED RATE 0.1 - 200 IPM
SPINDLE SPEEDS 0 - 7,500 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 15 HP AC (PEAK)
TOOL CHANGER CAPACITY 21 STATION ATC
MAXIMUM TOOL WEIGHT 15 LBS
EQUIPPED WITH:
FADAL CNC-88HS 32-BIT CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
