Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 20"
SWING OVER CARRIAGE 13"
MAXIMUM TURNING DIAMETER / LENGTH 11.4" / 15.7"
X AXIS TRAVEL 8.7"
Z AXIS TRAVEL 17.3"
B AXIS TRAVEL (SUB SPINDLE TRAVEL) 18.9"
C AXIS INDEXING 0.001 DEG.
RAPID TRAVERSE RATE X & B AXES 800 IPM
RAPID TRAVERSE RATE Z AXIS 1000 IPM
SPINDLE NOSE (MAIN / SUB) A2-6 / A2-5
SPINDLE BORE - MAIN SPINDLE 3"
MAIN SPINDLE SPEEDS 50 - 5,000 RPM
SUB SPINDLE SPEEDS 60 - 6,000 RPM
SPINDLE MOTOR (MAIN / SUB) 20 HP / 7.5 HP
TURRET CAPACITY (ALL STATIONS LIVE) 12 STATION TURRET
LIVE TOOLING MOTOR 3 HP
LIVE TOOLING SPEEDS 50 - 3,000 RPM
EQUIPPED WITH:
FANUC 18T CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
6" HYDRAULIC CHUCK ON MAIN, 5" ON SUB SPINDLE
SMW SPACESAVER 2000 MINIBAR SYSTEM, PARTS CATCHER
TOOL PRESETTER, PARTS OFFLOADING CONVEYOR
CHIP CONVEYOR, ALL AVAILABLE LIVE TOOLING HOLDERS
ALL AVAILABLE TURNING TOOL HOLDERS & MANUALS
