Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 19.7"
SWING OVER CARRIAGE 13"
MAXIMUM TURNING DIAMETER 14.6"
MAXIMUM TURNING LENGTH 20.9"
X AXIS TRAVEL 8.3"
Z AXIS TRAVEL 21.7"
RAPID TRAVERSE RATE X AXIS 630 IPM
RAPID TRAVERSE RATE Z AXIS 787 IPM
SPINDLE NOSE A2-8
SPINDLE BORE 3.4"
MAXIMUM BAR WORK DIAMETER 2.91"
SPINDLE SPEEDS 30 - 3,500 RPM
SPINDLE MOTOR 30 HP AC
TURRET CAPACITY 10 STATION TURRET
TAILSTOCK QUILL DIAMETER 4.3"
TAILSTOCK QUILL TAPER MT #4
TAILSTOCK QUILL TRAVEL 3.9"
EQUIPPED WITH:
FANUC 18T CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
3J HYDRAULIC THROUGH COLLET CHUCK SYSTEM
SMW SPACESAVER 2000 MAGAZINE BARFEED SYSTEM
TOOL PRESETTER, AUTOMATIC PARTS CATCHER
STANDARD COOLANT SYSTEM WITH TANK & PUMP
RIGHT HAND DISCHARGE CHIP CONVEYOR
ALL AVAILABLE TOOLING, ALL AVAILABLE MANUALS
