Specifications
Equipped With
GENERAL SPECIFICATIONS:
MAKE............................. CINCINNATI
MODEL............................ NO. 1
SERIAL NUMBER.................... 31501P5U-29
AGE (APPROX)..................... 1968
SWING OVER TABLE................. 8"
TABLE WORKING SURFACE............ 4" X 23"
LONGITUDINAL MOVEMENT OF TABLE... 10"
TABLE SWIVELS.................... 180 DEG.
SWIVEL TABLE ADJUST. (TAPER / FT) 2" TOWARD WHEELHEAD
................................. 1.5" AWAY
TABLE GRADUATIONS IN CENTER...... 90 DEG.
CROSS MOVEMENT OF WHEELHEAD SLIDE 4.5"
TOTAL CROSS RANGE OF WHEELHEAD... 7.5"
GRINDING WHEEL SPEEDS............ 3600 RPM @60 HZ
GRINDING WHEEL SPEEDS (6" WHEEL). 6110 FPM @60 HZ
GRINDING WHEEL SPEEDS (3.5")..... 5985 FPM @60 HZ
WEIGHT........................... 950 LBS.
CURRENT ELECTRICS................ 480 VOLTS
EQUIPPED WITH:
MANUALS
SPECIFICATIONS SUBJECT TO VERIFICATION
