Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER....................... CINCINNATI
MODEL.............................. HYPOWERMATIC
SERIAL ............................ 6B26D5E-11
TABLE SIZE ........................ 18" X 72"
RPM RANGE ......................... 22-900 RPM
SPINDLE TAPER...................... 50
DISTANCE BETWEEN SPINDLES.......... 24"
TABLE TRAVEL ...................... 48"
HORSEPOWER ........................ 20
VERTICAL TRAVEL ................... 14-1/2"
QUILL SIZE ........................ 8-1/2"
HYDRAULIC FEED MOTOR .............. 5 HP
WIRED ............................. 440V/3/60
EQUIPPED WITH:
WET BASE
MISC CHANGE GEARS
SPECIFICATIONS SUBJECT TO VERIFICATION
