Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 20.5" X 27.5"
MAXIMUM TABLE LOAD 770 LBS
SPINDLE NOSE TO TABLE TOP 5" - 25"
X AXIS TRAVEL 20"
Y AXIS TRAVEL 20"
Z AXIS TRAVEL 20"
RAPID TRAVERSE RATE X, Y & Z AXES 787 IPM
CUTTING FEED RATE 0.1 - 472 IPM
SPINDLE SPEEDS 60 - 6,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 10 HP AC
TOOL CHANGER CAPACITY 21 STATION ATC
MAXIMUM TOOL WEIGHT 15 LBS
MAXIMUM TOOL LENGTH 12"
EQUIPPED WITH:
ACRAMATIC 2100 PC-BASED CNC CONTROL WITH 9" TOUCH SCREEN
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPPING)
GIBBSCAM AT THE CONTROL, HIGH SPEED TOOL & DIE PACKAGE
FULL CONTROL HAND-HELD PENDANT FOR ACRAMATIC 2100
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
