Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER................................BUTLER
MODEL.......................................LE4000/VC1
SERIAL NUMBER...............................28437
NEW.........................................1993
SPINDLE TAPER...............................CAT. 50
RAM TRAVEL..................................41.3 (1050 MM)
RAM SIZE....................................18" X 17"
HEADSTOCK VERT. TRAVEL (Y)..................98" (2.5 METERS)
COLUMN TRAVEL (X)...........................354" (9 METERS)
HORSEPOWER..................................40
RPM RANGE (4 RANGES)........................1-2100 RPM
FEEDS INF. VARY.............................2-100 IPM
RAPID TRAVERSE RATE.........................360 IPM
TOOL CHANGER SIZE...........................60 TOOLS
EQUIPPED WITH:
FANUC 18M CONTROL
FULL LENGTH CHIP CONVEYOR
SET UP FOR PROBE
FLOOD AND THRU SPINDLE COOLANT
WAY COVERS
NOTE: WE HAVE VARIOUS VERTICAL AND HORIZONTAL ROTARY TABLES AVAILABLE FOR THIS MACHINE.
SPECIFICATIONS SUBJECT TO VERIFICATION
