Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1995
TABLE (SIZE) 33" X 37"
(ALLOWABLE LOAD) 2000 LBS
MEASURING RANGE (X AXIS) 29.5"
(Y AXIS) 25.6"
(Z AXIS) 19.7"
WORK CAPACITY (X AXIS) 32.6"
(Y AXIS) 37.0"
(Z AXIS) 22.7"
LINEAR DISPLACEMENT ACCURACY .0002" ALL AXES
REPEATABILITY .00012"
VOLUMETRIC PERFORMANCE .0004"
DIMENSIONS (APPROX.) 44" X 47" X 104"
SHIPPING WEIGHT (APPROX.) 1,700 LBS.
EQUIPPED WITH:
RENISHAW ELECTRIC TOUCH TRIGGER MIP PROBE
ADJUSTABLE AIR BEARINGS ON ALL THREE AXES
PC HARDWARE-486/66 MHZ CPU, MONITOR, PRINTER, MANUALS
B & S MICROMEASURE III SOFTWARE (DOS) W/CONTOUR &
STATISTICAL UPGRADE
TABLE CLAMP KIT
