Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE (WITHOUT / WITH DUST BOX) 16" x 13" / 13" x 10"
MAXIMUM TABLE LOAD 165 LBS
SPINDLE NOSE TO TABLE TOP 4.75" - 14.75"
X AXIS TRAVEL 15"
Y AXIS TRAVEL 15"
Z AXIS TRAVEL 10"
RAPID TRAVERSE RATE X, Y & Z AXES 600 IPM
CUTTING FEED RATE 0.1 - 600 IPM
SPINDLE SPEEDS (2 SPEED GEARED) 5,000 - 30,000 RPM
SPINDLE TAPER HSK 40
SPINDLE MOTOR (VECTOR DRIVE) 8 HP AC
TOOL CHANGER CAPACITY 6 STATION ATC
GRAPHITE REMOVAL SYSTEM CAPACITY 800 CFM DOUBLE FILTERED
POSITIONING (PER LITERATURE) +/- 0.00005 (NEW MACHINE)
REPEATABILITY (PER LITERATURE) +/- 0.00004 (NEW MACHINE)
EQUIPPED WITH:
BOSTOMATIC 32-BIT CNC CONTROL WITH 12" COLOR TOUCH SCREEN
RS-232C PORT INTERFACE FOR DNC OPERATION, REMOTE JOG HANDLE
RIGID TAPPING (SYNCHRONOUS TAPPING / SOLID TAPPING)
LASER TOOL MEASUREMENT SYSTEM, TOOL LIFE MANAGEMENT
COUNTOUR OPTIMIZATION, COMMAND RESOLUTION TO 6 DECIMAL PLACES
0.5 MICRON HEIDENHAIN GLASS SCALES ON ALL AXES
FULLY SEALED ENCLOSURE, AXES, CONDUITS, SCALES & TOOL CHANGER
SPINDLE CHILLER, THERM-A-TROL SPINDLE GROWTH COMPENSATION
HIGH CAPACITY HARD DRIVE, 3.5" FLOPPY, ETHERNET
POSITIVE AIR PRESSURE IN SPINDLE FOR GRAPHITE CUTTING
FULL DUST COLLECTION SYSTEM, REMOTE JOG HANDLE (RPG)
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
