Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1974
PUNCH CAP.:
FORCE 88 TON
STROKE 1-1/4"
SPEED 46 SPM
THROAT DEPTH 20"
MAX. CAP. THRU THICKNESS 1-1/4"-7/8", 1-1/16"-1"
ANGLE SHEAR CAP.:
90 DEG. 6" X 6" X ½"
45 DEG. 4" X 4" X ½"
SPEED 40 SPM
NOTCHER CAP.:
PLATE 19/32"
ANGLE 3-1/2" X 7/16"
WIDTH OF CUT 2-3/16"
DEPTH OF CUT 3-7/8"
SPEED 46 SPM
PLATE SHEAR CAP.:
FLAT 6" X ¾", 10" X ½"
SPEED 46 SPM
MOTOR 5.5 HP(208-240V/440-480V,3 PH)
DIMENSIONS (APPROX.) 78" X 32" X 78"
WEIGHT (APPROX.) 7,500 LBS.
EQUIPPED WITH:
12" X 12" PUNCH STATION FIXTURE TABLE
NEW PLATE SHEAR BLADE
BACK GAUGE FIXTURE ON PLATE SHEAR STATION
TUBE NOTCHING ATTACHMENT ON COPER/NOTCHER STATION
