Specifications
Equipped With
GENERAL SPECIFICIATIONS:
MANUFACTURER K.O. LEE
MODEL S709C3A
SERIAL # B800-12A
NEW (APPROX.) 1968
TABLE WORKING SURFACE 19" x 6"
TRAVEL (LONGITUDINAL) 20"
TRAVEL (CROSS FEED) 7-1/4"
CHUCK SIZE 6" x 18"
WORK HEIGHT (MIN.) 3-1/8"
WORK HEIGHT (MAX.) 15-1/2"
GRINDING WHEEL SIZE 8" x 3/4" x 1-1/4"
SPINDLE SPEED 2850 RPM
SPINDLE MOTOR 1 HP
HYDRAULIC PUMP 3/4 HP
DIMENSIONS (APPROX.) 68" x 43" x 5/12' H
WEIGHT (APPROX.): 2000 lbs.
EQUIPPED WITH:
ELECTROMAGNETIC CHUCK
HYDRAULIC/MANUAL FEED
COOLANT TEMPORARY SPECIFICATIONS SUBJECT TO VERIFICATION
