Specifications
Equipped With
SPECIFICATIONS:
Table size................................. 6" X 18"
Longitudinal travel........................ 19"
Cross travel............................... 6-3/4"
Spindle centre to table.................... 15 1/4"12"
Maximum grinding wheel size................ 8" X 1-1/4"
Spindle motor.............................. 1 HP
Spindle speed.............................. 3,450 RPM
Floor area cabinet......................... 40" X 31"
Floor space, operating..................... 68" X 45"
Approximate weight......................... 930 LBS
Electrics.................................. 220/440/3/60
EQUIPED WITH:
6" x 16" magnetic chuck, Fine feed on vertical and cross, coolant pump, lubrication pump
