Specifications
Equipped With
GENERAL SPECIFICATIONS:
SERIAL # 3A3923
NEW APPROXIMATELY 1954
ARM LENGTH:
(MAX. COLUMN TO SPINDLE DIST.) 6'
(MIN. COLUMN TO SPINDLE DIST.) 13.75"
COLUMN DIAMETER 17"
VERTICAL TRAVEL OF ARM ON COLUMN 38"
AREA OF SURFACE OF BASE 108" X 64"
MAIN MOTOR 15 HP
SPINDLE SPEEDS (36) 12-1200 RPM
SPINDLE TAPER #4MT
FEEDS (18) .004-.125 IPM
THREADS 8, 11.5, 14, 18 TPI
SPINDLE TRAVEL 18"
SPINDLE DIAMETER 3.1875"
DIMENSIONS (APPROX.) 150"L X 64"W X 32"H
WEIGHT (APPROX.) 27,000 LBS.
EQUIPPED WITH:
POWER CLAMPING
POWER ARM ELEVATION
POWER HEAD TRAVERSE
28" X 32" X 16" BOX TABLE
COOLANT
