Specifications
Equipped With
Specificatons:
Model...................................................6-250
capacity (tons).........................................50
Ram speed (inches per min.)..........................65 advance
(advance/press).........................................3 press
Number of pumps.........................................1
Air presure (pounds)....................................90-125
Width between uprights (in.)............................32-3/4
Width between table channels (inches)...................7-1/4
Minimum ram to table (in.)..............................5
Maximum ram to table (in.)..............................40
Ram travel (in.)........................................10
Horizontal workhead travel (in.)........................13-1/4
Base (inches)........................................43-1/2 x 36
Height (inches).........................................87
Weight (pounds).........................................1,100
Equipped With:
20 x 50 Work fixture table
Light Curtains
Palm Button
