GENERAL SPECIFICATIONS:
MANUFACTURER TECHNICA
MODEL ZSM-150
MAX. DIA. OF WORKPIECE 5"
MAX. LENGTH OF WORKPIECE 43"
CONE ANGLE OF GROUND CENTRE HOLES 60 DEG.
MAX. DIA. OF GROUND CENTRE HOLES 2"
HEADSTOCK AXIS TO COLUMN FACE 5"
GRINDING SPINDLE SPEEDS 15,000-22,500-45,000 RPM
QUILL SPEEDS 400, 800 RPM
FEED OF GRINDING CONE ALONG
SURFACE TO BE GROUND .030" - .200"
DIA. OF GRINDING CONES 3/4", 1-1/4", 1-3/4"
GRINDING SPINDLE MOTOR 1/2 HP, 2,800 RPM
QUILL DRIVING MOTOR 1/4 HP, 900 RPM
WEIGHT (APPROX.) 1,300 LBS.
DIMENSIONS (APPROX.) 38"W x 34"D x 71"H
