GENERAL SPECIFICATIONS:
MANUFACTURER........................ CLAUSING
AGE APPROXIMATELY................... 1974
MODEL............................... 4256
SERIAL#............................. 512H-717
SWING OVER THE TABLE................ 5"
MAX DISTANCE BETWEEN CENTERS........ 12"
MAX TABLE TRAVEL.................... 14"
TABLE SWIVEL EACH WAY............... 7.5 DEGREES
AUTO DWELL OF TABLE................. 0 TO 10SECONDS
GRINDING WHEEL...................... 10" X 1-1/2" X 3"
GRINDING WHEEL SPEEDS (2)........... 2200 AND 2600 RPM
HOLE THRU DRAW BAR.................. 1 1/8"
WORKHEAD SPINDLE CENTER............. #2 MT
TAILSTOCK SPINDLE CENTER............ #2 MT
DIMENSIONS.......................... 61" X 48" X 61"H
WEIGHT APPROX....................... 2000 LBS.
ELECTRICS........................... 240 VOLTS/3PHS/60HZ
EQUIPPED WITH:
POWER TABLE TRAVERSE
ADJUSTABLE TABLE DWELL W/TIMER
VARIABLE SPEED ON WORKHEAD
WORKHEAD ACCEPTS 5C COLLETS W/ DRAWBAR
UNIVERSAL SWIVELING WORKHEAD
