Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1992
SPINDLE (BAR) DIAMETER 4"
TABLE SIZE 39.37" x 44.09"
MAXIMUM TABLE LOAD 6,600 LBS
TRAVEL: X AXIS 55.11"
Y AXIS 39.37"
Z AXIS 31.5"
W AXIS 19.7"
INDEXING B AXIS 0.001 DEG.
RAPID TRAVERSE RATE:
X, Y, Z AXIS 283 IPM
W AXIS 157 IPM
B AXIS 0-1.3 RPM
CUTTING FEED RATE X,Y,Z,W AXIS 0.04 - 78 IPM
SPINDLE SPEEDS (2 SPEED RANGES) 5 - 1,250 RPM
SPINDLE TAPER # 50
SPINDLE MOTOR 15 HP AC
FLOOR SPACE DIMENSIONS 163" x 183" x 129"
EQUIPPED WITH:
FANUC OMC CNC CONTROL WITH 9" CRT
FULL CONTOURING B-AXIS W/ROTARY
RS-232C PORT INTERFACE FOR DNC OPERATION
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
TELESCOPING STEEL WAY COVERS
STANDARD COOLANT SYSTEM WITH TANK & PUMP
ALL AVAILABLE MANUALS
