35 Ton, DIACRO, No. 16-96,8'OA,62"BH,HYDRA-MECH.,FOMBG, 1977,

GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1977
SERIAL NUMBER 660097484
CAPACITY 35 TONS
BENDING CAPACITY (MILD STEEL) 8' x 16 GA.
OVERALL LENGTH OF BED & RAM 8'
DISTANCE BETWEEN HOUSINGS 62"
STROKE 2"
RAM ADJUSTMENT 3"
SHUT HEIGHT 9"
THROAT DEPTH 9"
MAIN DRIVE MOTOR 3 HP
DIMENSIONS APPROXIMATELY 96"L-R x 44"F-B
x 92" HIGH
WEIGHT APPROXIMATELY 5,500 LBS.

EQUIPPED WITH:
FRONT OPERATED BACK GAUGE
POWER RAM ADJUSTMENT
STROKE ADJUSTMENT
DUAL SPEED CYCLE (FAST APPROACH-SLOW PRESS-FAST RETURN) TEMPORARY SPECIFICATIONS SUBJECT TO VERIFICATION
