Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER: ...................... LION
MODEL:.............................. C13MB
YEAR:............................... 5292
NEW................................. 1994
SWING OVER BED:..................... 31.5"
SWING OVER CROSS SLIDE:............. 21"
SWING WITH GAP REMOVED:............ 41"
GAP LENGTH:......................... 12"
DISTANCE BETWEEN CENTERS:........... 120"
SPINDLE BORE:....................... 4 1/8"
SPINDLE NOSE........................ D1-11
SPINDLE SPEEDS:..................... 8 - 1000 RPM
SPINDLE MOTOR:...................... 20 HP
TAILSTOCK TAPER:.................... 6 MT
EQUIPPED WITH:
4 WAY RAPID TRAVERSE
2 STEADY RESTS (APPROX 8" & 18" CAP.)
25" 3-JAW CHUCK
WITH 7.5" HOLE
4 WAY TOOL POST
TAPER ATTACHMENT
CHIP PAN
COOLANT
INCH / METRIC THREADING
APPROX. WEIGHT 17,500 LBS
SPECIFICATIONS SUBJECT TO VERIFICATION
