Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1987
TWIN PALLET TABLE SIZES 19.7" x 45.3"
AXIS TRAVELS: X 30"
Y 20"
Z 20"
TOOL MAGAZINE CAPACITY 30
MAIN MOTOR 30 HP
SPINDLE TAPER CAT 40
CHIP TO CHIP TIME, APPROXIMATELY 8 SECONDS
RAPID TRAVERSE RATE: X & Y 945 IPM
: Z 590 IPM
SPINDLE SPEED 40-6000 RPM
DISTANCE FROM SPINDLE TO TABLE TOP 4"-39"
TABLE LOAD CAPACITY 1,540 LBS.
POWER REQUIREMENTS 24 KVA
WEIGHT APPROXIMATELY 13,500 LBS.
DIMENSIONS APPROXIMATELY 10' x 12' x 8.5'
EQUIPPED WITH:
MAZATROL CAM M-2 CONTROL
(2) PALLET CHANGER SYSTEM
COOLANT SYSTEM (53 GALLONS)
OIL CHILLER SYSTEM
REMOVABLE LOWER CHIP-PAN
FULL ENCLOSURE
SOME TOOLING
MANUALS
