Specifications
Equipped With
SPECIFICATIONS:
Manufacturer....................... HYDRAPOWER
Model.............................. SH-3020
Serial Number...................... G3074
Type............................... Hydraulic
Age................................ 1993
Capacity........................... 3/8" x 20' Mild Steel
Backgauge Range.................... 36"
Throat Depth....................... 18"
Table Height....................... 35"
Number of Hold downs............... 23
Main Motor Horsepower.............. 40 HP
Overall Dimensions (L x W x H)..... 268"L X 83"D x 71"H
Weight............................. 54,000 lbs.
Voltage............................ 480V 3Phase
Equipped with:
front operated power back gauge with manual fine adjustment
blade gap adjustment
hydraulic hold-downs
foot switch operation
6 support arms
requires approx. 24" deep x 20' long x 4" wide slot in the floor
