Specifications
Equipped With
#99171-7
GENERAL SPECIFICATIONS:
SERIAL T-7463
NEW APPROXIMATELY 1968
DOWNSTROKE MAXIMUM CAPACITY 28 TON
MAXIMUM PRESSURE 1980 PSI
CYLINDER DIAMETER 6"
RAM DIAMETER 4"
MAXIMUM STROKE 46"
APPROXIMATE MAXIMUM DOWNSTROKE SPEED 60 IPM
APPROXIMATE MAXIMUM UPSTROKE SPEED 120 IPM
THROAT DEPTH 12-1/2"
BED (BOLT ON BOLSTER) 24" X 20-1/2" X
2-1/2"
HOLE IN BED 5" DIA.
MAXIMUM DAYLIGHT 48"
EQUIPPED WITH:
HAND LEVER CONTROL
ADJUSTABLE MAIN RELIEF VALVE
GUIDED RAM
ADJUSTABLE RAM STROKE STOPS
VICKERS HYDRAULICS
MAIN MOTOR 10 HP
REMOVEABLE RAM NOSE
TONNAGE INDICATOR GAUGE
ELECTRICS 230/460/60/3
FLOOR SPACE 42" X 64"
OVERALL HEIGHT (FLOOR STANDING) 12-1/2'
APPROXIMATE WEIGHT 6,000 LBS.
MISCELLANEOUS TOOLING
IN-FRAME HYDRAULICS
