Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER............................. HEIM
SERIAL #................................. 2484
CAPACITY................................. 250 TON
NEW APPROXIMATELY........................ 1979
STROKE................................... 10"
SHUT HEIGHT.............................. 23.75"
RAM ADJUSTMENT........................... 6"
BED AREA................................. 102"LR x 48"FB
RAM AREA................................. 100"LR x 48"FB
WINDOWS.................................. 26" WIDE
STROKES PER MINUTE....................... 20 - 40 (VARIABLE)
EQUIPPED WITH:
AIR CLUTCH AND BRAKE
BOLSTER 102" x 48"
T-SLOTTED RAM
A/C MOTOR STARTER AND CONTROLS
REWORKED 2002
OVERALL HEIGHT 161" (14')
SHIPPING HEIGHT 12' 6"
