22" x 80" POLAMCO, MDL TUJ-50M, 3.5" HOLE, TAPER, COOLANT, INCH/METRIC, 10" 3- JAW CHK

GENERAL SPECIFCIATIONS:
MANUFACTURER POLAMCO (TARNOW)
MODEL TUJ-50M
SERIAL # 1181-1768
SWING OVER BED 22"
SWING IN GAP 31.5"
SWING OVER CROSS SLIDE 14.5"
DISTANCE BETWEEN CENTERS 80"
SPINDLE SPEEDS (14) 18 - 1600 RPM
MAIN DRIVE MOTOR 14 HP
ELECTRICS 230/3 PH
SPINDLE BORE 3.5"
70" THREADS/RANGE 1/4 TP - 56 TPI
59 METRIC THREADS/RANGE .5 TP - 112MM
TAILSTOCK SPINDLE 5 MT
SPINDLE NOSE D1-11
WEIGHT (APPROX.) 6,050 LBS.

EQUIPPED WITH:
10" 3-JAW CHUCK
TAPER ATTACHMENT
4-WAY TOOLPOST
COOLANT THRU
REMOVABLE GAP
