GENERAL SPECIFICATIONS:
MAKE...................... CLAUSING COLCHESTOR
MODEL..................... VS2180
SERIAL NUMBER............. 8116
AGE (APPROX).............. 1992
SWING..................... 21"
SWING OVER CROSS SLIDE.... 14.57"
SWING IN GAP.............. 32.6"
LENGTH OF GAP............. 8.5"
DIST. BETWEEN CENTERS..... 80"
HOLE THRU SPINDLE......... 3.5"
INCH THREADING (73)....... 2 TO 84 TPI
DIAMETRAL THREADING (27).. 8 TO 72
METRIC THREADING (51)..... 0.2 TO 14mm
MODULE THREADING (51)..... 0.2 TO 3.5
TAILSTOCK SPINDLE TAPER... MT-6
TAILSTOCK SPINDLE TRAVEL.. 7"
SPINDLE NOSE.............. D1-11 CAMLOCK
SPEED RANGE............... 40-2000 RPM
SPINDLE SPEEDS FORW/REV... 18
MOTOR..................... 15 HP
WEIGHT.................... 6300 LBS.
EQUIPPED WITH:
NEWALL DRO
RAPID TRAVERSE
16" 6-JAW CHUCK
STEADY REST
TAILSTOCK
INCH/METRIC THREADING
TAPER ATTACHMENT
FULL LENGTH SPLASH GUARD
COOLANT
SPECIFICATIONS SUBJECT TO VERIFICATION
