Specifications
Equipped With
MODEL NO. S. I. J.
SERIAL NO. 3038
COLD BENDING CAPACITY...............................10' X 2.5"
HOT BENDING CAPACITY(NORMALIZED AT 1680 DEGREES)....10' X 5"
(55" ID)
TOP ROLL DIAMETER...................................29.9"
BENDING ROLL DIAMETER...............................25.25"
BOTTOM ROLL DIAMETER................................28.125"
BOTTOM ROLL DRIVE MOTOR.............................175 HP
BENDING ROLL DRIVE MOTOR............................100 HP
ADJUSTING DRIVE MOTOR...............................30 HP
APPROXIMATE WEIGHT..................................107 SHORT
TONS
EQUIPPED WITH:
DIGITAL CONTROLS
NEW DRIVE BRONZE BUSHINGS
REFURBISHED AUTOMATIC LUBRICATION SYSTEM
Thickness MIN. INSIDE DIA MAX WIDTH
3.5" 50" 48"
3" 48" 72"
2 3/4" 46" 96"
2 1/2" 44" 120"
MIN 3/8" 32" 120"
