Specifications
Equipped With
GENERAL SPECIFICATIONS:
SERIAL 5HD305
NEW APPROXIMATELY 1969
SWING OVER BED 19"
SWING OVER CROSS SLIDE 12-1/2"
MAXIMUM DISTANCE BETWEEN CENTERS 60"
SPINDLE HOLE 1-3/4"
SPINDLE DRIVE MOTOR 10 HP
SPINDLE SPEEDS (16) 20-1550 RPM
THREADS PER INCH (48) 2-112
FEEDS INCHES PER REVOLUTION (96) .0006 - .104
SPINDLE NOSE L-1
TAILSTOCK TAPER NO 4 MT
ELECTRICS 220/60/3
SIZE 10-1/2'Lx4-1/2'Wx5-1/2'H
APPROXIMATE WEIGHT 4,500 LBS.
EQUIPPED WITH:
10" 3 JAW CHUCK
17" FACE PLATE
DYNA-TORQUE ELECTRO MAGNETIC CLUTCH/BRAKE
ADJUSTABLE AUTOMATIC LENGTH STOPS
TAPER ATTACHMENT
4 WAY TOOL HOLDER
MICROMETER STOP
WORK LIGHT
CHIP AND COOLANT PAN
COOLANT IN BASE
HARDENED AND GROUND WAYS
MULTIPLE THREAD CUTTING ADJUSTMENT
NO THREAD DIAL TEMPORARY SPECIFICATIONS SUBJECT TO VERIFICATION
