17" x 80" CLAUSING COLCHESTER, 10-1/2" SW OVER CS, 11" CS TRVL, 3-1/4" BORE, 12" 3 & 4 JAW CHK, INCH/METRIC TREADING

GENERAL SPECIFICATIONS:
MANUFACTURER CLAUSING COLCHESTER
SERIAL # 7/0017/02331
NEW (APPROX.) 1975
SWING OVER BED 17"
SWING OVER CROSS SLIDE 10-1/2"
CROSS SLIDE TRAVEL 11"
DISTANCE BETWEEN CENTERS 80"
SPINDLE NOSE 8" D-1 CAMLOCK
SPINDLE BORE 3-1/4"
SPINDLE SPEEDS 20 - 1600 RPM
ELETRICS 220/440/3 PH/60 CYC
WEIGHT (APPROX.) 6,000 LBS
DIMENSIONS (APPROX.) 140" x 32" x 52"

EQUIPPED WITH:

12" 4-JAW CHUCK
INCH/METRIC THREADING
