15.75" LARGE BORE 3 JAW SCROLL CHUCK, 8.66" BORE, 500 MAX. RPM

Chuck Dia	15.750000
RPM max	500
Weight	128
Model	PSL3-16"
a	4.7200
B	4.1300
b	5/8" - 11
c	0.7500
D H7	14.2520
F	15.0000
M	M12 x 40
Thru Hole E	8.66
Jaw Stroke Min	6.6140
Jaw Stroke Max	11.3400
wt. of workpiece (without support)	110
wt. of workpiece (with support)	3,301
Line Drawing

PSL Series Large Thru Hole Chucks

• 3 Jaw Self-Centering
• Forged steel body, Large Thru-hole
• Plain back
• Medium Duty

• Two-piece Reversible American Standard Tongue and Groove Jaws.
• Designed for pipe machining or pipe welding cut-off operations.
• Balanced scroll.
• Can be used on lathes, rotary tables and welding devices.
• Jaws, scroll plate, and three pinions are made of fine alloy steel, then carefully heat treated and ground.
