Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER LANDIS
SERIAL NUMBER 526-7
MODEL TYPE F
SWING OVER TABLE 30" (762 MM)
MAX. WORK PIECE DIAMETER 23" (609 MM)
CENTER DISTANCE 168" (4267 MM)
MAXIMUM WHEEL SIZE 36" x 3" X 12"
SPINDLE MOTOR 40 HP (18 KW)
OVERALL LENGTH 34'
EQUIPPED WITH:
NEW SPINDLE MOTOR AND AC VARIABLE FEED DRIVE IN 2005
DC WORK HEAD
LIVE CENTERS
NEW SPINDLE BEARINGS ON GRINDING WHEEL 2005
HYDRAULIC TABLE FEED
COOLANT SYSTEM
TWO WORK SUPPORTS
GRINDING WHEELS
WHEEL DRESSER
VARY SPEED ON WORK HEAD AND GRINDING WHEEL
DRESSER ON THE BACK OF THE TAILSTOCK
WAYS LOOK EXCELLENT
