Specifications
Equipped With
GENERAL SPECIFICATIONS:
MAKE.................................. HYD-MECH
MODEL................................. S-20A
SERIAL NUMBER......................... 80401097
NEW................................... 2001
CAPACITY ROUND AT 90 DEGREES.......... 13"
CAPACITY ROUND AT 45 DEGREES.......... 12"
MAX. HEAD SWIVEL...................... 45 DEGREES
CAPACITY RECTANGULAR AT 90 DEGREES.... 13" X 18"
BLADE SPEEDS.......................... 75-400 SFM (INF. VARIABLE)
MAX. SHUTTLE STROKE................... 29"
BLADE MOTOR........................... 3 HP/208-230/460 VOLTS
HYDRAULIC DRIVE....................... 2 HP
CURRENT VOLTAGE....................... 440 VOLTS
WEIGHT APPROX......................... 3000 LBS.
BLADE SIZE............................ 1" X 13'6" X .032"
EQUIPPED WITH:
AUTOMATIC PART FEED
BUNDLE CLAMPING
MITERING
COOLANT
HYDRAULIC DOWNFEED
ADJUSTABLE BLADE TENSION
