Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER..................... ATEK BANTAM
MODEL............................ B212
SERIAL #......................... E0128
NEW APPROXIMATELY................ 2001
RATED CAPACITY................... 12 TON
RATED CAPACITY (MILD STEEL)...... 11 GA. X 20", 3/16" X 12"
1/4" X 9", 3/8" X 6"
OVERHEAD BED LENGTH & DIST.
BETWEEN HOUSINGS.............. 24"
STROKE ADJUSTMENT................ 0" - 1-3/4"
DIE SPACE........................ 7"
BED ADJUSTMENT................... 2"
BACK GAUGE DEPTH................. 18" MAX.
RAM HEIGHT....................... 5-7/8"
SPEED............................ 30 - 35 SPM
WEIGHT W/FLOOR STAND (APPROX.)... 700 LBS.
EQUIPPED WITH:
24" FLOOR STAND
STANDARD BACKGAUGE
FOOT PEDAL
AIR FILTER/LUBRICATOR/REGULATOR
UPPER & LOWER DIES
