Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER...................... AMETEK/RIEHLE
MODEL............................. VT-10
NEW APPROXIMATELY................. 1971
TESTING CAP. RANGES (1)........... 10,000 IN/LB x 20 LB INCR.
LOADING SPEED (1 DIR/SINGLE)...... 180 DEG./MIN.
DISTANCE BETWEEN CHUCK............ 0 - 18"
SPECIMEN DIAMETER................. 1/4" TO 1"
OVERALL DIMENSIONS................ 63"Lx23"Dx37"H
.................................. (67.5" TALL ON STANT)
APPROXIMATE WEIGHT................ 1,200 LBS.
ELECTRICAL REQUIREMENTS........... 115V, 60HZ, 1PH
