Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY............................... 1993
MAX. GRINDING LENGTH............................ 20"
MAX. GRINDING WIDTH............................. 10"
MAX. DISTANCE BETWEEN SPINDLE
CENTER TO TABLE SURFACE......................... 19-1/2"
TABLE SPEED (HYDRAULIC)......................... 16-80 FPM
DOWN FEED GRADUATION DIAL:
(PER GRADUATION).............. 0.0005"
(PER REVOLUTION).............. 0.1"
CROSS FEED GRADUATION DIAL:
(PER GRADUATION).............. 0.001"
(PER REVOLUTION).............. 0.2"
FINE FEED INCREMENT DIAL:
(PER GRADUATION).............. 0.0001"
(PER REVOLUTION).............. 0.01"
SPINDLE MOTOR................................... 2 HP
HYDRAULIC MOTOR................................. 2 HP
CROSS FEED MOTOR................................ 1/6 HP
POWER ELEVATION MOTOR........................... ¼ HP
SPINDLE SPEED................................... 3580 RPM
STANDARD WHEEL SIZE............................. 8" X 1-1/4" X ½"
APPROX. WEIGHT.................................. 3000 LBS.
EQUIPPED WITH:
PERMANENT MAG CHUCK
WHEEL DRESSER
AUTOMATIC DOWN FEED
SPECIFICATIONS SUBJECT TO VERIFICATION
