Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER........................ STEELWELD
MODEL............................... 4B-6
SERIAL NUMBER....................... M-8110
AGE.................................
SHEARING CAPACITY MILD STEEL........ 1/4" X 6'
STROKES PER MIN..................... 60
RAKE ANGEL (TAPER PER FT)........... 1/4"
KNIFE SIZE.......................... 4" X 1" X 6'4"
MAIN DRIVE MOTOR.................... 10 HP
APPROX. DIMENSIONS.................. 11' X 6'6" DEEP X 7'6" TALL
APPROX. SHIPPING WEIGHT............. 20,000
ELECTRICS........................... 440/480 V
EQUIPPED WITH:
36" FRONT RIGHT OPERATED BACK GAUGE WITH LENGTH INDICATOR
FRONT OPERATED KNIFE CLEARANCE CONTROL
FLUSH FLOOR DESIGN (NO PIT)
2 FRONT GAUGE ARMS WITH STANDARD STOPS
ELECTRIC FOOT SWITCH
AIR CLUTCH
SPECIFICATIONS SUBJECT TO VERIFICATION
