Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER...................... CINCINNATI
MODEL............................. 1812
SERIAL #.......................... 23870
NEW APPROXIMATELY................. 1949
CUTTING CAP. (MILD STEEL)......... 12' X 1/4"
OVERALL LENGTH OF KNIVES.......... 148"
DISTANCE BETWEEN HOUSINGS......... 147"
GAP DEPTH, THROAT................. 18"
RAKE ANGLE........................ 1/4"/FOOT
DISTANCE FLOOR TO TOP OF BED...... 32"
DISTANCE UNDER HOLD DOWNS......... 9/16"
HOLD DOWNS TO KNIFE EDGE.......... 5/8"
RAM ADJUSTMENT.................... 11/16"
SPEED (APPROX.)................... 60 SPM
MOTOR............................. 15HP/3/60
DEPTH OF SLOT REQ. IN FLOOR....... 6"
WEIGHT (APPROX.).................. 20,000 LBS.
DIMENSIONS (APPROX.).............. 178"LR x 92"FB x 81"H
EQUIPPED WITH:
36" REAR OPERATED BACK GAUGE
ELECTRIC FOOT SWITCH OPERATION
6' SQUARING ARM
13 HYD. HOLD DOWNS/RAM COUNTER BALANCES
AUTOMATIC LUBRICATION SYSTEM
2 SHEET SUPPORT
