Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1998
CUTTING: LENGTH 122"
CAP. MILD STEEL 1/4"
CAP. STAINLESS .166"
STROKES PER MINUTE 19
# OF HOLDDOWNS 14
BLADE: SIZE 3/4" x 2"
MATERIAL X210 CR12
HARDNESS 58 HRRC
THROAT DEPTH 4-1/2"
BACKGAUGE ADJUSTMENT 39-3/8"
HEIGHT OF TABLE FROM FLOOR 31-1/4"
HYDRAULIC TANK CAPACITY 53 GALLONS
MAIN DRIVE MOTOR 20 HP
OVERALL DIMENSIONS 145-3/4"Lx106-1/4"Wx69"H
WEIGHT 12,320 LBS.
STANDARD EQUIPMENT:
FRONT OPERATED POWER BACKGAUGE
ALL STEEL CONSTRUCTION
T-SLOTTED SQUARING ARM WITH DISAPPEARING STOP
EXTENDED SHEET SUPPORTS WITH DISAPPEARING STOP
SINGLE HANDLE BLADE ADJUSTMENT
GAP FOR SLITTING OPERATION
SHADOW LINE CUTTING
RIGIDLY MOUNTED BLADE GUARD
MULTIPLE EDGE BLADES
KEY LOCK CONTROL PANEL
FOOT CONTROL PEDAL
HYDRAULIC HOLD DOWNS
SECTIONAL BLADES (3)
