Specifications
Equipped With
SPECIFICATIONS:
CAPACITY IN MILD STEEL:
AT NOMINAL RAKE OF 3/8" 1/2" X 12'
AT INCREASED RAKE OF 1/2" 5/8" X 12'
LENGTH BETWEEN HOUSINGS 12'-3"
DEPTH OF THROAT 18"
BACK GAGE RANGE 48"
FRONT GAGE RANGE 65-3/8"
SPEED, FULL LOAD DOWN 135 IPM
SPEED, RETURN 290 IPM
STROKES PER MINUTE:
FULL LENGTH CUT 13
STROKES PER MINUTE:
24" CUT 40
HOLDDOWNS (12" CENTERS WITH EXTRA
HOLDDOWNS AT BOTH ENDS 19
HOLDDOWN FORCE, TONS 55
APPROXIMATE SHIPPING WEIGHT 66,900 LBS.
EQUIPPED WITH:
EXTRA SET OF BLADES
HYDRAULIC HOLDDOWNS
FRONT CONTROLLED POWER OPERATED BALL BEARING
BACK GAGE WITH DIRECT READING INDICATOR
SOLID BACK GAGE ANGLE
WATER COOLED OIL COOLER
HOLDDOWN TONNAGE CONTROL
HOLDDOWN AND KNIFE GUARDS
ADJUSTABLE RAKE
ADJUSTABLE STROKE
BALL TRANSFERS IN TABLE
FOUR FRONT GAGE SUPPORT ARMS WITH STOP FOR EACH ARM
AUTOMATIC PRESSURE LUBRICATION
SINGLE STROKE CONTROL, INCLUDING "INCH" AND "RUN"
OPERATION
