Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1981
SERIAL 1181G2318
NOMINAL CAPACITY MILD STEEL 1/2" x 10'
MAXIMUM CAPACITY MILD STEEL:
AT MAXIMUM RAKE & SHARP BLADES 3/4" x 10'
RAKE PER FOOT :NOMINAL 3/8" - 1/2"
:HIGH CAPACITY MAXIMUM 5/8"
CUTTING WIDTH 124"
NUMBER OF HYDRAULIC HOLD DOWNS 11
BLADE SIZE 1" x 4"
CYCLES PER MINUTE: FULL LENGTH CUT 9.5
: 1/2 LENGTH CUT 15
: 12" CUT 26
SPEED INCHES PER MINUTE: DOWN 123
: UP 192
MAIN DRIVE MOTOR 40 HP
ELECTRICS 220/440/60/3
OVERALL SIZE D x W x H 8-1/2' x 12-1/2' x 9'
APPROXIMATE WEIGHT WITH BALL FIELD 25,000 LBS.
EQUIPPED WITH:
36" FOPBG
FLUSH FLOOR MOUNT
WORK LIGHT CANOPY ONLY
POWER RAKE ADJUSTMENT
POWER BLADE GAP ADJUSTMENT
FOOT SWITCH
STROKE LENGTH CONTROL
SWING AWAY BACK STOP
2' BED DEPTH
ONE 3' SQUARE ARM & ONE 7' SQUARE ARM
MANUAL CENTRAL LUBE
BED WITH (3) HAND SLOTS & (2) T-SLOTS
10' SQUARE FLOOR PLATE WITH (22) WHEEL FRONT SUPPORT FIELD
HOLD SWITCH & INCHING CONTROL
